SUZUKI KING QUAD 300 LT-F300 LTF300 LT-F300F 1999 2000 2001 2002 2003 2004 SERVICE REPAIR MANUAL

SUZUKI KING QUAD 300 LT-F300 LTF300 LT-F300F 1999 2000 2001 2002 2003 2004 SERVICE REPAIR MANUAL

1999 – 2004

Loaded with illustrations, instructions, photos, and diagrams, complete to service and repair your SUZUKI. Read and print pages or copy the entire manual to your hard drive.

384 Pages

MODELS COVERED:

• 2004 Suzuki LT-F300FK4
• 2003 Suzuki LT-F300FK3
• 2002 Suzuki LT-F300FK2
• 2001 Suzuki LT-F300FK1
• 2001 Suzuki LT-F300K1 2WD
• 2000 Suzuki LT-F300FY
• 2000 Suzuki LT-F300Y 2WD
• 1999 Suzuki LT-F300FX
• 1999 Suzuki LT-F300X 2WD

MANUALS COVER:

~ GENERAL INFIRMATION

~ PERIODIC MAINTENANCE

~ ENGINE

~ SHAFT DRIVE AND DIFFERENTIAL GEARS

~ FUEL AND LUBRICATION SYSTEM

~ CHASSIS

~ ELECTRICAL SYSTEM

~ SERVICING INFORMATION

This manual is the same as the manual used by workshops. Service Manual contains detailed instructions and step by step diagrams for all workshop procedures.

 Language: English
Format: PDF – Indexed and Searchable

COMPATIBLE WITH ALL WINDOWS & MAC COMPUTERS
(WINDOWS 11, WINDOWS 10, WINDOWS 8 ETC.)

Windows/Mac/Tablet/Phone Friendly

• Engine: A 280cc, SOHC (Single Overhead Camshaft), four-stroke, single-cylinder engine that provides abundant torque in the low and mid-ranges.
• Transmission: A triple-range transmission features five speeds plus reverse, with a three-speed sub-transmission (high, low, and super-low) for versatility in various working conditions.
• Drivetrain: The
  LT-F300F

   model offered three drive modes: 2WD, 4WD, and front differential-locked 4WD, all easily accessed via a lever. The final drive is integrated into the rear.

• Suspension: A four-wheel independent suspension system, with double A-arms in the front and a diagonal swing axle in the rear, provided a comfortable ride and 8.3 inches of ground clearance.
• Brakes: The ATV featured dual hydraulic disc brakes in the front for strong stopping power in both wet and dry conditions, and a single mechanical drum brake in the rear.
• Electrical System: It used a CDI (Capacitor Discharge Ignition) electronic ignition system for reliability, as well as both electric and recoil starting.
• Wheels: The
  LT-F300F

   is easily identified by its five-lug rear wheels.

• Carburetor: The King Quad 300 uses a Mikuni BSR29 carburetor. If the ATV sputters during acceleration, inspect the vacuum petcock and check the carburetor jets and float bowl for clogs caused by old fuel or debris.
• Electrical: A common problem can be ignition timing issues due to CDI unit failure, leading to poor throttle response. Issues can also be related to a faulty voltage regulator/rectifier.
• Oil consumption: Some owners report that the King Quad 300 can burn a small amount of oil. It is important to check the oil level regularly and use ATV-specific 10w40 oil, as car oil is not suitable for the wet clutch.
• Parts availability: Since the ATV is an older model, parts may be more difficult to find. However, both OEM and aftermarket parts are available through online retailers and parts stores.
• Starting: The engine has a compression release lever on the cylinder head for easier pull-starting.

• Online marketplaces: eBay is a common source for used Suzuki LT-F300F ATVs, as well as both new and used parts, including carburetors, stators, and voltage regulators.
• Online parts retailers: Websites like MotoSport and NAPA Auto Parts carry both OEM and aftermarket parts for the LT-F300F, and MotoSport offers parts diagrams.
• Used vehicle marketplaces: Check online listings on sites like Craigslist or local classifieds for private sales. J.D. Power can provide estimated values for models like the 2002 Suzuki LT-F300FK2.
• Service manuals: Digital copies of the service and repair manuals for the 1999–2004 King Quad 300 are available through online stores.
