POLARIS SPORTSMAN XP850 XP850EPS 2009 Service Repair Manual

POLARIS SPORTSMAN XP850 XP850EPS 2009 Service Repair Manual

Loaded with illustrations, instructions, photos, and diagrams, complete to service and repair your POLARIS. Read and print pages, or copy the entire manual to your hard drive.

310 Pages

Models Covered :

2009 SPORTSMAN XP850

2009 SPORTSMAN XP850 EPS

Model Year:

2009

Manual Covers :

• General Information
• Maintenance
• Engine
• Cooling System
• Fuel System/Carburetion
• Body
• Steering
• Suspension
• PVT System
• Clutch
• Final Drive
• Transmission Service
• Brakes
• Wiring Diagram

This manual is the same as the manual used by workshops. Service Manual contains detailed instructions and step by step diagrams for all workshop procedures.

 Language: English
Format: PDF – Indexed and Searchable

COMPATIBLE WITH ALL WINDOWS & MAC COMPUTERS
(WINDOWS 11, WINDOWS 10, WINDOWS 8 ETC.)

Windows/Mac/Tablet/Phone Friendly

• Engine: The 850 XP EPS is powered by an 850cc liquid-cooled, four-stroke, twin-cylinder engine with four valves per cylinder and electronic fuel injection (EFI), producing 70 horsepower.
• Chassis and suspension: The new frame featured a narrower mid-section, improving rider comfort. The dual A-arm suspension was revised, with 9 inches of wheel travel in the front and 10.25 inches in the rear.
• Power steering: The EPS system provided variable assistance, reducing steering effort at low speeds and offering more feedback at higher speeds.
• Storage and towing: The ATV featured a Lock and Ride system on the redesigned cargo racks. It has a front rack capacity of 120 pounds and a rear rack capacity of 240 pounds, with a towing rating of 1,500 pounds.
• Additional features: The vehicle came with three headlights, four-wheel disc brakes, and a digital gauge cluster.

• Stalling and irregular idle: Some owners of the 850 XP have reported the machine stalling or bucking when shifting out of neutral. Possible causes include issues with the fuel filter, injectors, throttle position sensor (TPS), or idle air control valve (IAC).
• Frame issues: Some owners have reported frame problems, though the severity depends on the machine’s use and maintenance.
• Airbox issues: An airbox leak can cause engine damage. Some owners also report engine oil in the airbox, which a dealer may attribute to normal machine function.
• Recalls: The 2009 model was subject to two safety recalls issued by Polaris:
  • Crankcase breather valve (July 2009): This recall involved a crankcase breather valve that could fail in sub-freezing temperatures, causing crankcase pressure to increase. The pressure could lead to an oil leak that could cause a fire.
  • Steering knuckle (December 2009): A defective suspension system could cause a loss of steering control if the front suspension ball joint stem separated from the steering knuckle.

• Performance parts
  • Clutch kits: The Mother Clutcher Primary and
    Secondary Clutch Bundle

     is available from retailers like Harvey’s ATV Parts and eBay.

  • ECU tuning: OE Tuning offers ECU performance tunes for the 2009 Sportsman 850 EFI EPS.
• Maintenance and repair
  • Brake pads: Front and rear sintered brake pads are available from third-party sellers on eBay.
  • Suspension: Tie rod end and tie rod kits can be found on eBay, from brands like Caltric.
  • Body panels: OEM and used body panels can be found through various retailers, including Leaders RPM and eBay.
  • Service manual: A PDF version of the service manual is available online.
• Accessories
  • Cargo and storage: A front storage box is available, and many retailers carry other items like cargo racks, pod bags, and winches.
  • Protection: Front brush guards and handguards are available from third-party retailers.
